Quicrun Fusion 8Ight Se For Crawler 1800Kv

Introducing the QuicRun Fusion 8IGHT SE Crawler Integrated Power System.

Integrated Design
The Fusion 8IGHT SE is FOC integrated power system, specifically designed for 1/8th scale models. Its compact frame layout measures 41×69mm, making it a powerful yet space-efficient solution for builders. The integrated design creates an ultra easy to install system, that makes for an extremely clean setup.

4S 1/8th Crawler ESC
The ESC is designed to support up to 4S LiPo, delivering a maximum continuous output current of up to 60A. Its compact design makes it suitable not only for 1/8th climbing models, but also for 1/7th light-load climbing models.

FOC for Super Linearity & High Torque & Extreme Mute

The Fusion 8IGHT SE adopts FOC driving mode. Low speed torque is extremely powerful and smooth providing drivers ultra fine control and response under load. FOC provides superior response to standard brushless or brushed motor setups. In addition to ultra fine low speed power, the system is extremely quiet, nearly silent when in operation.

Intelligent Torque Output & Speed Closed-loop Control for Easy Control
The ESC intelligently adjusts torque output to match driving conditions, automatically increasing torque to overcome resistance and accelerate uphill. Reducing torque to stabilise vehicle speed when descending. This smart torque management ensures precise speed control and smooth performance, delivering a consistently responsive driving experience.

QuicRun Fusion 8IGHT SE
Note: When operating in normal mode, the ESC does not have a fixed speed function, providing a driving experience similar to that of a traditional brushed motor.

Suitable for All Weather and Conditions
The entire power system is rated IP67, offering outstanding waterproof and dust-proof performance. This allows drivers to tackle any terrain ranging from ice, snow, sand and water, knowing their system will perform flawlessly.

Note:
The IP67 protection level mentioned above provides splash-proof, water-resistant, and dust-proof capabilities under normal use. However, it is not permanently effective, as protective performance may diminish over time due to regular wear and aging. Avoid prolonged immersion in water, as it may result in product damage.

Supports Three Operating Modes
The system supports multiple operating modes to meet various application needs.

Fixed Speed Mode
(Direct Forward and Reverse)
Normal Mode without
Fixed Speed Functionality
(Forward and Reverse with Brake)
Normal Mode without
Fixed Speed Functionality
(Direct Forward and Reverse)

Supports LED / LCD Program Boxes
The ESC is compatible with both basic LED program box and advanced LCD program box.

Variety of Parameters
The Fusion 8IGHT SE offers a wide range of customisable parameters, with a total of 11 adjustable seings to accommodate diverse application requirements and fine-tune performance.

Specifications
Continuous / peak current: 60A/200A
Lipo Cells: 2-4S Lipo
BEC output: 6V/7.4V adjustable,
continuous current 4A (Switch mode)
Programming port:
Independent Programming Port(Switch Position)

Size/Weight: 41mm×69mm/ 326.5g
(Including Wires & Connectors)
Motor KV: 1800KV
Diameter / Length of motor: 41mm / 69mm
Shaft diameter / exposed shaft length: 5mm / 18.5mm
Crawler Motor Poles: 4
