Ripmax  |  QZ553

Ripmax Quartz Servo - Brushless HV (0.11sec/33.7kg)


£57.59
RRP: £63.99
Save £6.40
Notify me when available
The This high quality, high performance servo is intended to appeal to discerning modellers that only want the best. It's plastic case, ball-race, plastic gears, regular motor and digital amplifier provides the perfect solution to your servo needs at an unbelievable price.

The case centre is CNC machined from solid Aluminium for the very best in strength and rigidity. The Main Case is made from heavy duty plastic helping to reduce cost and weight.

Check through the specifications and performance and we are sure you will agree!
Specifications / Technische Daten
Lead Length / Kabellänge: 265mm
Dead Band / Totbereich: 1us 1520us / 330hz
Weight / Gewicht: 65g
Electric Motor / Elektromotor: Brushless
Connector / Verbinder: JR Style
Bearings / Lager: 2 x BB
Dimensions / Abmessungen: 40.5 x 20.5 x 40mm
Speed / Geschwindigkeit: 0.13sec / 60° @ 6V
Speed / Geschwindigkeit: 0.11sec / 60° @ 7.2V
Torque / Kraftmoment: 26.7kg / cm
Torque / Kraftmoment: 33.7kg / cm
